AS-100 2STEP
Mechanical Parameters
Up/Down angle of swing arm: ±30°
Table size: 840mm×405mm
Table rotational angle: 90°
Table sliding movement: 330mm
Angle of rotation for chair: ±60°
Lifting height for chair: 150~200mm
Loading for chair: 70~150kgs
Lifting height for pillow: ＋150mmLifting height for pillow: ＋150mm
Backrest obliquity: 90°~135°or 140°
Electrical Parameters:
Input voltage: 110V/220V AC 50Hz~60Hz
"Engine power: 55W 24V DC "
Light luminaire: 40W 110V/220V AV
Fuse: 5A 250V AC
Power without load: 1W
Pressure test: 2KV
Main wire: 10A 250V
Working mode: S1
"Working temperature: －30º~＋50º"
Relative humidity: less than 90%
Force of pressing key: 1~5N
Installation Dimension
Figure size: 1100mm×1000mm×2110mm
Weight: 98kgs
