AV-7000 Auto phoropter
Specifications
Sphere: -29.00D~+26.75D 0.12D/0.25D/0.50D/1.00D/3.00D steps
Cylinder: -8.75D~+8.75D 0.25D steps
Axis angle: 0~180° 1°/5°steps
Pupillary Distance: Distant range: 48~80mm 0.5/1mm steps
Close range: 50~70mm 0.5/1mm steps
Rotary Prism: 0~20 0.1 /0.5 /1.0 steps
Cross Cylinder Lens: ±0.25D/±0.50D
Plane Retinoscope: +1.50D(67cm) +2.00D(50cm)
Auxiliary Lens:
PH Binoculus(=1.0mm)
RMV,RMH
RL(Right eye),GL(Left eye)
Polaroid(Right eye 135°/45°; Left eye 45°/135°)
Prism(Right 6 BU ,Left 10BI)
Cross Cylinder Lens (±0.50D Axis=90°)
PD Lens
Major Size: 436mm×260mm×110mm
Net Weight: 7.2Kg
Keyboard Size: 246mm×205mm×185mm
Power Box Size: 292mm×186mm×124mm
Power Supply: AC 220V 50HZ or AC 110V 60HZ,90W
