ARP-600 LED Chart projector
1） LCD Screen - all the software and hardware are designed by our engineers from Taiwan.
2） The software is specially designed for professional use in ophthalmic equipment and not using “WINDOWS” software
3） Operation of the equipment is simple and easy
4) Since the software is not “WINDOWS” based, when power is turned off and on again, the software information is not lost and hence start up time is very quick. In the case of using “WINDOWS” software, once the power is off and on again, one needs a long restart time just like a computer.
A
1）Independent software system, with no proprietary problems
2）Displaying as powered up, no waiting
3）No data loss when meets with power failure
4）4 LCD screens can be in operation at the same time with no interruption
5）4 kinds of clock dails: ①dotted line15° ②solid line15° ③dotted line10° ④solid line10°
6）Internal SD card, updating the software system is convenient anytime
7）Controlled by remote controllor
8）Can be linked to the RIGHTWAY Auto Vision Tester AV-600
B
1) Panel:19"(4:3)
2) Pixel pitch: 0.285mm
3) Max.brightness:300cd/m2
4) Max.contrast ratio: 800:1
5) Max.resolution:1280×1024@75HZ
6) Input signal: RGB
7) Sigal joint: 15Pin D Pattern Plug
8) Energy consumption: 35W
9) Net weight: 5KG
10) Compatibility: PC/MAC
11) Dimension: 60（D）×425(W) ×440(H)mm
C Placement
1) Can be hung on the wall by a trestle
2) Can stand on ground by a support
3) Can be set on the table
